① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
■ Activating the function
＋ －
or
① Select the "MIX" item
and then select the ON
or OFF by pressing the
+ key or – key.
● When you do not use a function, set to the
"INH" side.
■ Switch selection
＋ －
or
② Select the "SW" item
and then select the
switch by pressing the
+ key or – key.
Range：SwA ～ SwD
■ Switch direction
＋ －
or
③ Select the "POSI
" by pressing the
+ key or – key at
the ON direction
selection item.
Range：
● 2P SW：NULL, UP, DOWN
● 3P SW：NULL, UP, UP&DWN,
UP&CNT, CENTER, CNT&DN, DOWN
■ Mixing rate
＋ －
or
④ Select the "RATE" item and
then adjust the mixing rate by
pressing the + key or – key.
Range：-100 ～ +100% Default：+50%
● When you want to return the set value to the initial
value, press the + key and – key simultaneously.
However, polarity does not return.
● RATE↑/↓ cursor position operates and chooses an
elevator stick.
Elevator → Flap Mixing
This mixing is used when you want to apply
mixing from elevator to ap. Usually, mixing
is such that the ap are lowered by raising the
elevator. When used with Fun Fly and other
aircraft, small loops are possible.
●The up side and down side rates can be
adjusted.
"EL → FLP"
EL → FLP
Elevator → Flap mixing
(AIRPLANE)
Mixing rate
Activating the function
Switch selection
Switch direction
（Elevator up side rate）
（Elevator down side rate）
● When not using this Function
select INH. The display of On/
O is shown when active and
assigned to a switch.
● Select the setting item
with the Jog key.
● Sets the ON/OFF direction of the selected switch.
○ 2P SW：NULL, UP, DOWN
○ 3P SW：NULL, UP, UP&DWN, UP&CNT, CENTER, CNT&DN, DOWN
Flap 5
Elevator
CH5
CH2
Select the ↑/↓ with the
elevator stick .
To Next Page
