FUTABA 6k - Stick Control: Airplane Example

Before use
26
Stick control : Airplane Example
A general model example. (There is also a di󱐯erent operational model.)
Right roll
Left roll
Straight
A rudder is to
the right.
A rudder is to
the left.
The left aileron
is in the down.
The left aileron
is in the up.
Level flight
Level flight
The right aileron
is to the up.
The right
aileron is to
the down.
Elevator is a
up.
Elevator is a
down.
Aileron stick
To the right
Neutral
Neutral
Nose Up
Nose Down
Middle
Hight
Slow
Roll axis Control
Yaw axis Control Throttle Control
Elevator stick
UP
(moved to the bottom)
Elevator stick
DOWN
(moved to the top)
Aileron stick
To the left
Pitch axis Control
Rudder stick
To the right
Neutral
Rudder stick
To the left
Nose Right
Nose Left
Throttle stick
MIDDLE
(neutral)
Throttle stick
HIGHT
(moved to the top)
Throttle stick
SLOW
(moved to the bottom)
*Example Stick Mode2
