① Call the menu screen from the
home screen by pressing the +
key for 1 second.
＋
② Select
from the menu with the
Jog key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
■ Mode
① Select the "MODE" item and then select the
mode by pressing the + key or – key.
＋ －
or
Range：NOR, ESC
Default：NOR
● "NOR"：Engine plane
"ESC"：Electric motor plane
■ Activating the function
② Select the "MIX" item and then select the o
by pressing the + key or – key.
＋ －
or
● When you do not use a function, set to the
"INH" side.
Throttle Cut
This function cuts (stops) the engine or motor
by stick operation. At throttle operation, the rate is
adjusted to the position which completely cuts the
throttle servo or ESC when the throttle is operated.
When THR CUT is active, the throttle position is
held regardless of the throttle stick position.
●The throttle position when the function is reset
can be set so the motor will not unexpectedly
run at high speed when the throttle cut function
is reset. When the throttle stick is higher than the
set throttle position, the throttle cut function is not
reset even if the switch is set to OFF. Set to a safe
throttle position (slow side).
(NOR/ESC mode the next page referring.)
●Function operation can be selected from among
switches A
〜
D.
●Set the throttle cut function for safety also.
"THR CUT"
THR CUT
Throttle cut
(AIRPLANE)
Mode
Cut Position rate
Throttle Position
Switch selection
● When not using this Function
select INH. The display of On/
Off is shown when active and
assigned to a switch.
● Adjusts the rate to the position
that completely cuts the
throttle servo or ESC.
● The value in parentheses is the
current throttle stick position.
● Select the setting item
with the Jog key.
● Sets the ON/OFF direction of the selected switch.
○ 2P SW：NULL, UP, DOWN
○ 3P SW：NULL, UP, UP&D, UP&C, CNTR, C&DN, DOWN
Activating the function
To Next Page
