① Call the menu screen from the
home screen by pressing the + key
for 1 second.
＋
② Select
from the menu with the Jog
key.
③ Open the setting screen by
pressing the Jog key.
（1 second）
Calling the setting screen
① Select the trim you want to set from the STEP item
and set the step size by pressing the + key or – key.
＋ －
or
Range：1～40
Default：4
● When you want to return the
set value to the initial value,
press the + key and – key
simultaneously.
① Select the trim you want to set from the TYPE item
and set the trim type by pressing the + key or –
key.
＋ －
or
Range：NOR, CNT, ATL
(THR)
Trim step
Trim type
Trim Type
The amount of trim change trim type can be
changed between NOR (normal), ATL and CNT
(center) according to the trim application.
Trim Step
The amount of trim change per step can be
changed between 1 and 40 according to the aircraft
capacity and trim application.
Set it to match the application. With ordinary
● For example, when the step size is the initial value (4), trim movement from
center to end is 30 steps. If the step size is made 40, the trim moves 3 steps.
"TRIM"
Trim step
● Select the item with the
Jog key.
（Trim step rate）
TRIM
Trim reset ／ Trim step
(Common)
TRIM (Besides THR) NOR ⇔ CNT
CNT : With the center trim feature,
trim adjustments have no
eect on the maximum servo
travel. This prevents the
linkages from binding when
adjustments are made.
THR TRIM ATL ⇔ NOR
ATL : With the ATL trim feature,
trim adjustments have
no effect on the high
throttle. This prevents the
linkages from binding when
adjustments are made.
aircraft, a setting of about 2 to 10 should be fine.
(Initial value: 4)
To Next Page
