（1 second）
＋
END
HELICOPTER Function
The setting screen of each function is called from the following menu. The function when
the model type was set to helicopter is displayed here.
MENU
● When the + key is pressed for
1 second, the menu screen is
displayed.
● When the END key is
pressed, the display
returns to the home
screen.
MENU
3/4
MENU
2/4
MENU
1/4
MENU
4/4
（Home screen）
PowerON
● First set the
throttle to slow.
● Then turn on the power.
（Selection）
● Move the cursor
(highlighted) up and
down and to the left and
right with the Jog key and
select the function.
The cursor can be moved
over several pages.
（Calling the setting screen）
● Press the Jog key to open the
setting screen.
To menu screen
by holding down
the + key
The SWSH type
is indicated
every several
seconds.
HR3
To Next Page
