36
TLM
WARNING & ERROR DISPLAYS
An alarm or error indication may appear on the display of your transmitter for a number of
reasons, including when the transmitter power switch is turned on, when the battery voltage is
low, and several others. Each display has a unique sound associated with it, as described below.
LOW BATTERY ERROR:
Warning sound: Continuous beep until transmitter is powered off.
The
LOW BATTERY
warning is displayed when the transmitter battery voltage drops below 4.1V.
Land your model as soon as possible before loss of control
due to a dead battery.
MIXING ALARM WARNING:
Warning sound: Several beeps repeated until problem resolved or
overridden.
The
MIXING ALARM
warning is displayed to ALARM you
whenever you turn on the transmitter with any of the mixing
switches active. This warning will disappear when the offending
switch or control is deactivated. Switches for which warnings
will be issued at power-up are listed below. Throttle cut, idle-down, airbrake, motor SW,
ight MD, throttle-stick and condition. If turning a switch OFF does not stop the mixing
warning: The functions described previously probably use the same switch and the OFF
direction setting is reversed. In short, one of the mixings described above is not in the OFF
state. In this case, reset the warning display by pressing both
＋
/
－
KEY at the same time.
Next, change one of the switch settings of the duplicated mixings.
*If "ESC mode" is chosen by "THR.CUT", a THR CUT will not start warning.
BACKUP ERROR:
Warning sound: Several beeps (repeated continuously)
The
BACKUP ERROR
warning occurs when the transmitter memory is lost for any reason. If this
occurs, all of the data will be reset when the power is turned on again.
Do not y when this message is displayed: all programming
has been erased and is not available. Return your transmitter to
Futaba for service.
A setup of warning of each sensor can be performed in
TELEMETRY
.
LOW BATT
"TLM" mark is shown about
warning of TELEMETRY.
