20
When Using The Optional Battery HT5F1800B
NiMH battery HT5F1800B
(not included)
Refer to the previous
description and remove the
transmitter battery cover.
After removing the dry
cell battery box from the
transmitter, disconnect the
connector.
Insert the connector of the
new battery and load the new
battery into the transmitter.
Connect the battery
connector.
Finish by installing the
battery cover.
Disconnect the
connector
Dry cell
battery BOX
Charging jack
CAUTION
When closing the battery
cover, be careful that the
battery cover does not pinch
the battery lead wires.
Shorting of the battery lead wires may
lead to fire and abnormal heating and
cause burns or fire disaster.
When using an optional rechargeable battery, replace the battery as described below.
-Always use the optional HT5F1800B rechargeable battery.
-The type of power source used must be set by system setting.
-When the transmitter will not be used for a long time, remove the battery.
Charging a NiMH Battery
(Example: When using the HT5F1800B with the special charger)
1
Plug the transmitter cord of the special charger into
the charging jack on the rear of the transmitter.
2
Plug the charger into an AC outlet.
3
Check that the charging LED lights.
When Charging the Optional Battery HT5F1800B
