IIDTool
GAP Diagnostic 2019-07-15 All Rights Reserved
User Manual : Version 33, Firmware V3.0
WARNING
User should not alter any safety features. User should inform
himself of the applicable regulations or laws before making any
changes susceptible of being part of a law or regulation.
4.10.2 Uploading a conguration change
II BCM and LCM Congurations (L322-02, L322-06)
Ifacongurationchangeismade,itwilltakee󰀨ectwhentheuserreturnstothelistofECUsorwhen
thecongurationischanged.Whenthebutton is pressed or when certain settings are changed, the
message“Congurationschanged,applytothevehicle?+tocontinue,-tocancel”willbedisplayed.
If no changes were made, the IIDTool returns to the ECUs list.
II Car Conguration File
If a modicationof the CCF has been made, itwill be applied to the vehiclewhen the user exits
thecongurationmenu.Bypressing the button the user can decide to update the CCF with the
changes.Thefollowingmessageappears:“Congurationschanged,applytothevehicle?+toconti-
nue, - to cancel ”. If no changes were made, the IIDTool return to the menu.
App BCM, LCM and CCF congurations
Simply select “Upload Changes” and follow instructions on screen.
Steps
When updating the CCF, the IIDTool will prompt you with instructions to follow:
• Iftheengine’srunning,thefollowingmessagewillbedisplayed:“Enginerunning.TurnOFFen-
gine turn ignition ON (position II)”. L322-10, L319-10, L320-10, L405, L494, L538, L359 2013
onwards, theIIDToolwillturntheengineo󰀨automatically.
• The IIDTool will verify that the voltage is higher than 11.5 V. If not, the operation will be aborted.
• Themessage“Displaywillturno󰀨XYseconds,keepkeyONatalltime,<+>”willbedisplayed.
II Pressing any button will start the CCF write. During this phase, do not turn o󰀨 ignition or
disconnect the IIDTool.
• All pre-2010 and L359 up to 2012 vehicles: Once the display turns ON again, you will be
asked to turn the ignition OFF and back ON (position II), once done, press the button.
All 2010+ and L359 2013+ vehicles: Once the display turns ON again, the “Clearing Fault” and
“Upload Success” messages will appear. Turn OFF the ignition for at least one minute.
• The“ClearingFault”and“UploadSuccess”messageswillappear,II press the button to quit.
• All 2010+ and L359 2013+ vehicles: Turn ON the ignition for 30 seconds then start the engine.
If error messages are still present, use the Clear All function of the IIDTool.
Notes : During or after a conguration programming you may experience one or more of the following:
• It is normal to see warning lights appear on the display.
• Writing the CCF will disable the one touch window operation. To enable the one touch operation,
