Gap Diagnostic IIDTool - Body Control (L319-04, L320-05)

170
IIDTool
GAP Diagnostic 2019-07-15 All Rights Reserved
User Manual : Version 33, Firmware V3.0
Body Control (L319-04, L320-05)
UpdatingtheBCMBodyControlECUaddsthe3turnashfeature.Towork,itwillalsohavetobe
enabledintheCarCongurationFile(CCF).
Table 40. Risk, updating the Body Control ECU
• Re-ashingtheBodyControlECUtakesaround2.5minutes.
• GoodelectricalconnectionsattheOBDconnectorandhighenoughbatteryvoltageareboth
criticaltothesuccessoftheBCMre-ash.
• Ifyoudonothaveaccesstoapowersupply(Midtronic’sPSC-550,CTEKMXS25orequi-
valent), use jump cables and another vehicle with the engine running to supply current to the
battery.
• Donotusearegularbatterycharger.
• Makesureyouhaveplentyoftimeaheadbeforeproceeding.
• ifre-ashingfailsontherstattempt,fuses15and16oftheenginefuseboxwillhavetobe
removed quickly to prevent damages to latches or other devices controlled by the BCM. We
strongly recommend loosening the fuses using pliers before updating the BCM. This way, it will
be easier to remove both of them quickly in case of a failure.
Recovery Method
Ifafailureoccurredandasecondattemptisneeded,selectthefunctiontore-ashtheBCMandwhen
themessage“ToggleFuse”isdisplayed,reconnectfuse15.There-ashwillstartautomaticallyand
once completed, reconnect fuse 16. If it failed on the second attempt also with only fuse 15 installed,
try again with fuse 16 only.
If the recovery method was not successful, please contact the manufacturer for additional support :
support@GAP-Diagnostic.com.
Figure 105. Battery fuse holder location
Figure 106. Fuses 15 and 16, Body Control
ECU
Risk Level Consequences Recovery Method Precautions
High
Vehicle unusable, damage to
rear latch or other possible
Instructions below Mandatory
