4.1.2 Denitions and examples of Functions usage
Here’sabriefdenitionofo󰀨eredfunctionsaswellasasmallsampleofpossibleusage.Usagepro-
cedures of Functions and Sub Functions are available in referenced sections. The Integrated Interface
(II) Menu Trees are in Appendix.
Function
Name
Denition Example of usage
Manual
Section
Version
Allowsviewingthecurrentrmware
version of the IIDTool
Version 3.0 Build 2006
section
4.2
Read Faults
Reading faults indicates the possible
presence of an electrical or mechani-
cal problem.
Understand why a warning light is dis-
played on the instrument pack.
section
4.3.1
Clear Faults Erasing faults registered by ECUs
ex : Clear a Fault indicating an undetec-
ted tire valve
section
4.3.2
Advanced
Read
Further Faults analysis to check the
level of completion of faults detection
tests
Checkifspecicfaultsarestillundertest
section
4.3.4
Height
Change the height of the air suspen-
sion
ex : Raise the standard height by 10 mm
section
4.4
Height Control
Change the current height mode (Nor-
mal, o󰀨-road or Access). Lower the
rear axle down to the bump stops.
Change height mode from outside the
vehicle for easier loading.
section
4.5
Calibration
Calibration of sensors which have
undergone replacement or repair
ex : Steering angle sensor
section
4.6
Service Test
Complementary action for the diagno-
sis, repair and others
Resetting the oil counter
section
4.7
Live Values
Monitoring and visualization of
sensor or actuator status
Allows identifying conditions present
when diagnosis is performed
section
4.8
Control IO
Sensors and actuators control for
testing system components
ex : Simulate temperature to verify the
system response
section
4.9
CarCongura-
tion
Modifythecongurationleofthe
vehicle to customize a behaviour.
Activate the rear-view screen after instal-
ling a rear-view camera.
section
4.10
ECU Flash UpdatingECUrmwares
UpdatetheBluetoothECU(phone)tox
some pairing problems
section
4.11
ECU Info
Visualization of information for each
ECU detected
VerifyiftheECUrmwareisuptodate
section
4.12
Save and Res-
tore
Save and recall suspension calibra-
tion.Restorecongurationvalues.
ex:Resetcongurationsastheywere
whenusingthetoolforthersttime.
section
4.13
