4.4 Function “ Height ”
4.4.1 Denition
For height changes, the function allows changing either front, rear, or all corners simultaneously. These
changeswillalsoa󰀨ecttheothermodesasthestandardheightisthereferencepoint.Forexample,if
thestandardmodeisloweredby10mm,accessmode,motorway,ando󰀨-roadheightswillalsobe10
mm lower.
On L322-02, theo󰀨-road,motorwayandaccessmodescanalsobechanged.
WARNING
The IIDTool allows changing of vehicle settings to a state out-
side of the original manufacturer specication. It is the sole
responsibility of the user to choose secure settings for the
applicable use of the vehicle.
Notes :
• If values for the standard height are set too low (L322-02 without raising the values for access
and motorway heights) the vehicle may reach the bump stops in access mode:
-All except L322-02 In this case the EAS ECU registers a bottomed out condition and enters
‘Extended Mode’ automatically raising the vehicle (to allow the vehicle to drive out of the bot-
tomed out condition).
-L322-02 If the height indicator light continues blinking after the vehicle was switched o, this
can cause a battery drain.
• The height values are given in millimetres. This does NOT correspond exactly to changes in
height at the wheel. Measure all values to be sure.
• If the values for the standard height are set too high (and/or O-Road height on a L322-02) the
suspension can reach a fully extended condition in o-road mode. In this condition, there is no
upward suspension travel. There is a severe risk of damaging components and the vehicle
can become uncontrollable in this state! GAP Diagnostics assumes no liability for damages
or injuries incurred during use or resulting from the use of the IIDTool.
• Changes in height are instantaneous in the EAS ECU but the ECU won’t apply these changes
immediately. The EAS ECU will adjust a corner when it’s +/- 10 mm or higher than the desired
height. For example, if the corner is at +9 mm, it will not adjust the height.
