48
IIDTool
GAP Diagnostic 2019-07-15 All Rights Reserved
User Manual : Version 33, Firmware V3.0
Figure 20. OBDII Connector L322 2002-2006
Figure 21. OBDII Connector L316
Range Rover 2002-2006
The OBDII port is located above the storage
compartment under the driver side headlight
switch. Lower hinged cover to access the
connector.
Defender
The OBDII port is located in the driver side
fuse block. The cover must be open to access
the connector.
