GE 745 TRANSFORMER MANAGEMENT RELAY User Manual

6-2 745 Transformer Management Relay GE Power Management
6.2 A1 STATUS 6 ACTUAL VALUES
6
6.2 A1 STATUS 6.2.1 DESCRIPTION
Some status information is displayed by the front panel indicators. More status details can be viewed from the
first page of actual values. This information includes date and time, logic input status and output relay status.
6.2.2 DATE AND TIME
6.2.3 LOGIC INPUTS
6.2.4 VIRTUAL INPUTS
yy ACTUAL VALUES
yy A1 STATUS
This is the header of Actual Values page A1 STATUS. To view these actual
values press or press to go to the next page header.
y DATE AND TIME
y [ENTER] for more
This message indicates the start of the Date and Time actual values. To view
these actual values press or press for the next section.
CURRENT DATE:
Jan 01 2001
The current date is displayed in this message.
CURRENT TIME:
00:00:00
The current time is displayed in this message.
y LOGIC INPUTS
y [ENTER] for more
This message indicates the start of the Logic Inputs actual values. To view
these actual values press or press for the next section.
LOGIC INPUT 1
STATE: Not Asserted
This message displays the state of logic input #1. Similar messages appear
sequentially for logic inputs 2 through 16.
SETPOINT ACCESS
STATE: Open
This message displays the state of the setpoint access jumper. Setpoints
cannot be changed from the front panel when the state is opened.
y VIRTUAL INPUTS
y [ENTER] for more
This message indicates the start of the Virtual Inputs actual values. To view
these actual values press or press for the next section.
VIRTUAL INPUT 1
STATE: Not Asserted
This message displays the state of virtual input #1. Similar messages appear
sequentially for Virtual inputs 2 through 16.
MESSAGE
ACTUAL
ENTER
MESSAGE
ENTER
MESSAGE
ENTER
MESSAGE
