2.1 USING THE FRONT PANEL DISPLAY 2 GETTING STARTED
2
Let us review how we got to this last message.
1. First, we started at the setpoints page header
S1 745 SETUP
.
2. We then moved to the second sub-header message under page S1, which is
PREFERENCES
, and we
pressed the key.
3. We then moved to the last message in this group.
A path can be used as a means of specifying where a message is located in the 745 relay. For this last mes-
sage, the path would be
S1 745 SETUP / PREFERENCES / DEFAULT MESSAGE INTENSITY
. For the purposes of this
manual, we will refer to messages in this manner. Press the key to return to the preferences sub-header
message. Pressing the key from any of the messages under a sub-header will return the display to that
sub-header message. From a sub-header message, the repeated pressing of moves the display
through the list of sub-header messages to the page header. As an alternative, you could press the key
and move directly to the next page.
ENTER
ESCAPE
ESCAPE
MESSAGE
SETPOINT
