GE 745 TRANSFORMER MANAGEMENT RELAY User Manual

GE Power Management 745 Transformer Management Relay 6-5
6 ACTUAL VALUES 6.3 A2 METERING
6
b) POSITIVE SEQUENCE CURRENTS
All sequence component phase angles are referenced to Winding 1 phase A current.
c) NEGATIVE SEQUENCE CURRENTS
d) ZERO SEQUENCE CURRENTS
y POSITIVE SEQUENCE
y [ENTER] for more
This message indicates the start of the Positive Sequence Current actual
values. To view these actual values press or press for the
next section.
W1 POS SEQ CURRENT:
0A at 0°Lag
This message displays the positive sequence current magnitude and phase
for Winding 1.
W2 POS SEQ CURRENT:
0A at 0°Lag
This message displays the positive sequence current magnitude and phase
for Winding 2.
W3 POS SEQ CURRENT:
0A at 0°Lag
This message displays the positive sequence current magnitude and phase
for Winding 3.
y NEGATIVE SEQUENCE
y [ENTER] for more
This message indicates the start of the Negative Sequence Current actual
values. To view these actual values press or press for the
next section.
W1 NEG SEQ CURRENT:
0A at 0°Lag
This message displays the negative sequence current magnitude and phase
for Winding 1.
W2 NEG SEQ CURRENT:
0A at 0°Lag
This message displays the negative sequence current magnitude and phase
for Winding 2.
W3 NEG SEQ CURRENT:
0A at 0°Lag
This message displays the negative sequence current magnitude and phase
for Winding 3.
y ZERO SEQUENCE
y [ENTER] for more
This message indicates the start of the Zero Sequence Current actual
values. To view these actual values press or press for the
next section.
W1 ZERO SEQ CURRENT:
0A at 0°Lag
This message displays the zero sequence current magnitude and phase for
Winding 1.
W2 ZERO SEQ CURRENT:
0A at 0°Lag
This message displays the zero sequence current magnitude and phase for
Winding 2.
W3 ZERO SEQ CURRENT:
0A at 0°Lag
This message displays the zero sequence current magnitude and phase for
Winding 3.
NOTE
ENTER
MESSAGE
ENTER
MESSAGE
ENTER
MESSAGE
