GE Power Management 745 Transformer Management Relay 8-7
8 COMMUNICATIONS 8.2 MODBUS PROTOCOL
8
8.2.10 FUNCTION CODE 05H: EXECUTE OPERATION
Modbus implementation: Force Single Coil
GE Power Management implementation: Execute Operation
This function code allows the master to perform various operations in the 745. The 2 byte CODE VALUE of
FF00h must be sent after the OPERATION CODE for the operation to be performed.
MESSAGE FORMAT AND EXAMPLE:
Request to perform reset operation in slave device 11.
Master Query Message: Example (hex):
SLAVE ADDRESS 11 query message for slave 11
FUNCTION CODE 05 execute operation
OPERATION CODE: high order byte 00 remote reset
OPERATION CODE: low order byte 01
CODE VALUE: high order byte FF perform operation
CODE VALUE: low order byte 00
CRC: low order byte DF
CRC: high order byte 6A
Field: Example (hex):
SLAVE ADDRESS 11 response message from slave 11
FUNCTION CODE 05 execute operation
OPERATION CODE: high order byte 00 remote reset
OPERATION CODE: low order byte 01
CODE VALUE: high order byte FF perform operation
CODE VALUE: low order byte 00
CRC: low order byte DF
CRC: high order byte 6A
Table 8–2: SUMMARY OF OPERATION CODES FOR FUNCTION CODE 05H
OPERATION
CODE
DEFINITION DESCRIPTION
0000 NO OPERATION Does not do anything.
0001 REMOTE RESET Performs the same function as the front panel RESET key.
0002 TRIGGER TRACE
MEMORY
Initiates a waveform capture of trace memory and increments the "Total Number
of Trace Triggers" registers.
0003 CLEAR MAXIMUM
DEMAND DATA
Performs the same function as the command in message
A2 METERING / DEMAND
/ DEMAND DATA CLEAR / CLEAR MAXIMUM DEMAND DATA
.
0004 CLEAR EVENT
RECORDER DATA
Performs the same function as the command in message
A3 EVENT RECORDER /
EVENT DATA CLEAR / CLEAR EVENT RECORDER DATA
.
0005 CLEAR LOSS-OF-
LIFE DATA
Performs the same function as the command in message
S1 745 SETUP /
INSTALLATION / CLEAR LOSS-OF-LIFE DATA
.
0006 CLEAR TRACE
MEMORY
Clears all trace memory buffers and sets the "Total Number of Trace Triggers"
register to zero.
0007 CLEAR ENERGY
DATA
Performs the same function as the command in message
A2 METERING / ENERGY /
ENERGY DATA CLEAR / CLEAR ENERGY
.
