GE Power Management 745 Transformer Management Relay 5-31
5 SETPOINTS 5.3 S1 745 SETUP
5
5.3.11 745 OPTIONS
Some of the options supported by the 745 may be added while the relay is in the field. These include the Ana-
log I/O, Loss Of Life and Restricted Ground Fault options.
Should this be desired, contact the factory with the following information:
• The 745 order code (found under
A4 PRODUCT INFO/REVISION CODES/INSTALLED OPTIONS
).
• The 745 serial number (found under
A4 PRODUCT INFO/REVISION CODES/SERIAL NUMBER
).
• The new option(s) that are to be added.
The factory will supply a passcode that may be used to add the new options to the 745. Before entering the
passcode and performing the upgrade, it is important to set the
ENABLE
setpoints correctly (see below). Any
options that are currently supported by the 745 as well as any options that are to be added should have the
corresponding
ENABLE
setpoint set to
Yes
. All others must be set to
No
.
For example, if the 745 currently supports only the Analog I/O option and the Loss Of Life option is to be
added, then the
ENABLE ANALOG I/O?
setpoint and the
ENABLE LOSS OF LIFE?
setpoint must be set to
Yes
. The
ENABLE RESTRICTED GROUND FAULT?
setpoint must be set to
No
.
y UPGRADE UPTIONS
y [ENTER] for more
This message indicates the start of the
UPGRADE OPTIONS
section. To
continue with these setpoints press , or press to go to the
previous section.
ENABLE ANALOG I/O?
Yes
Range: Yes / No
ENABLE LOSS OF LIFE?
Yes
Range: Yes / No
ENABLE RESTRICTED
GROUND FAULT? Yes
Range: Yes / No
ENTER PASSCODE:
Enter passcode supplied by the manufacturer.
UPGRADE OPTIONS?
Yes
Range: Yes / No
ENTER
MESSAGE
