9 745 PC SOFTWARE 9.3 USING 745PC
9
Checked boxes indicate that the user has visited the setpoint during this session.
9.3.5 VIEWING ACTUAL VALUES
The following example illustrates how any of the measured or monitored values can be displayed. In the follow-
ing example the winding currents are examined:
1. Select the
Actual > Metering > Currents
menu item.
2. 745PC displays the following dialog box detailing the winding currents. To view any of the currents avail-
able click on the desired tab shown at the top of the box. For example, to view the positive, negative and
zero sequence currents in any of the windings click on the
Sequence
tab.
Figure 9–14: 745PC ACTUAL VALUES WINDOW
Checked boxes indicate that the user
has visited the setpoint during this session.
