GE 745 TRANSFORMER MANAGEMENT RELAY User Manual

6-6 745 Transformer Management Relay GE Power Management
6.3 A2 METERING 6 ACTUAL VALUES
6
e) DIFFERENTIAL CURRENT
The differential current phase angles are referenced to Winding 1 phase A current.
f) RESTRAINT CURRENT
g) GROUND DIFFERENTIAL CURRENT
y DIFFERENTIAL
y [ENTER] for more
This message indicates the start of the Differential Current actual values. To
view these actual values press or press for the next section.
PHASE A DIFFERENTIAL
CURRENT: 0.00 x CT
This message displays the differential current magnitude for phase A.
PHASE A DIFFERENTIAL
ANGLE: 0°Lag
This message displays the differential current angle for phase A.
PHASE B DIFFERENTIAL
CURRENT: 0.00 x CT
This message displays the differential current magnitude for phase B.
PHASE B DIFFERENTIAL
ANGLE: 0°Lag
This message displays the differential current angle for phase B.
PHASE C DIFFERENTIAL
CURRENT: 0.00 x CT
This message displays the differential current magnitude for phase C.
PHASE C DIFFERENTIAL
ANGLE: 0°Lag
This message displays the differential current angle for phase C.
y RESTRAINT
y [ENTER] for more
This message indicates the start of the Restraint Current actual values. To
view these actual values press or press for the next section.
PHASE A RESTRAINT
CURRENT: 0.00 x CT
This message displays the restraint current magnitude for phase A.
PHASE B RESTRAINT
CURRENT: 0.00 x CT
This message displays the restraint current magnitude for phase B.
PHASE C RESTRAINT
CURRENT: 0.00 x CT
This message displays the restraint current magnitude for phase C.
y GND DIFFERENTIAL
y [ENTER] for more
This message indicates the Ground Differential Current actual values. To
view these actual values press or press for the next section.
W1 GND DIFFERENTIAL
CURRENT: 0.000 x CT
This message displays the ground differential current magnitude for Winding
#1.
W2 GND DIFFERENTIAL
CURRENT: 0.000 x CT
This message displays the ground differential current magnitude for Winding
#2.
W3 GND DIFFERENTIAL
CURRENT: 0.000 x CT
This message displays the ground differential current magnitude for Winding
#3.
ENTER
MESSAGE
ENTER
MESSAGE
ENTER
MESSAGE
