GE 745 TRANSFORMER MANAGEMENT RELAY

6-14 745 Transformer Management Relay GE Power Management
6.4 A3 EVENT RECORDER 6 ACTUAL VALUES
6
W1 PHASE A CURRENT
0 A at 0° Lag
This message displays the phase current magnitude and phase angle for
phase A of winding 1 at the moment of the event.
W1 PHASE B CURRENT
0 A at 0° Lag
This message displays the phase current magnitude and phase angle for
phase B of winding 1 at the moment of the event.
W1 PHASE C CURRENT
0 A at 0° Lag
This message displays the phase current magnitude and phase angle for
phase C of winding 1 at the moment of the event.
W1 GROUND CURRENT
0 A at 0° Lag
This message displays the ground current magnitude and phase angle for
winding 1 at the moment of the event.
W1 (% ƒo) H2a: 0.0
H2b: 0.0 H2c: 0.0
This message displays the magnitude of the second harmonic current for
each phase of winding 1 at the moment of the event.
W1 (% ƒo) H5a: 0.0
H5b: 0.0 H5c: 0.0
This message displays the magnitude of the fifth harmonic current for each
phase of winding 1 at the moment of the event.
W2 PHASE A CURRENT
0 A at 0° Lag
This message displays the phase current magnitude and phase angle for
phase A of winding 2 at the moment of the event.
W2 PHASE B CURRENT
0 A at 0° Lag
This message displays the phase current magnitude and phase angle for
phase B of winding 2 at the moment of the event.
W2 PHASE C CURRENT
0 A at 0° Lag
This message displays the phase current magnitude and phase angle for
phase C of winding 2 at the moment of the event.
W2 GROUND CURRENT
0 A at 0° Lag
This message displays the ground current magnitude and phase angle for
winding 2 at the moment of the event.
W2 (% ƒo) H2a: 0.0
H2b: 0.0 H2c: 0.0
This message displays the magnitude of the second harmonic current for
each phase of winding 2 at the moment of the event.
W2 (% ƒo) H5a: 0.0
H5b: 0.0 H5c: 0.0
This message displays the magnitude of the fifth harmonic current for each
phase of winding 2 at the moment of the event.
W3 PHASE A CURRENT
0 A at 0° Lag
This message displays the phase current magnitude and phase angle for
phase A of winding 3 at the moment of the event.
W3 PHASE B CURRENT
0 A at 0° Lag
This message displays the phase current magnitude and phase angle for
phase B of winding 3 at the moment of the event.
W3 PHASE C CURRENT
0 A at 0° Lag
This message displays the phase current magnitude and phase angle for
phase C of winding 3 at the moment of the event.
W3 GROUND CURRENT
0 A at 0° Lag
This message displays the ground current magnitude and phase angle for
winding 3 at the moment of the event.
W3 (% ƒo) H2a: 0.0
H2b: 0.0 H2c: 0.0
This message displays the magnitude of the second harmonic current for
each phase of winding 3 at the moment of the event.
