8-52 745 Transformer Management Relay GE Power Management
8.3 MODBUS MEMORY MAP 8 COMMUNICATIONS
8
2068 Reserved
↓↓ ↓ ↓↓↓ ↓
206F Reserved
WINDING 1
PHASE INST
O/C 1
2070 Winding 1 Phase Inst O/C 1 Function --- --- --- F30 1 = Enabled
2071 Winding 1 Phase Inst O/C 1 Target --- --- --- F46 1 = Latched
2072 Winding 1 Phase Inst O/C 1 Pickup 0.05 to 20.00 0.01 x CT F3
1000 = 10.00 x CT
2073 Winding 1 Phase Inst O/C 1 Delay 0 to 60000 1 ms F1 0 ms
2074 Winding 1 Phase Inst O/C 1 Block --- --- --- F87 0 = Disabled
2075 Reserved
↓↓ ↓ ↓↓↓ ↓
207F Reserved
WINDING 2
PHASE INST
O/C 1
2080 Winding 2 Phase Inst O/C 1 Function --- --- --- F30 1 = Enabled
2081 Winding 2 Phase Inst O/C 1 Target --- --- --- F46 1 = Latched
2082 Winding 2 Phase Inst O/C 1 Pickup 0.05 to 20.00 0.01 x CT F3 10.00 x CT
2083 Winding 2 Phase Inst O/C 1 Delay 0 to 60000 1 ms F1 0 ms
2084 Winding 2 Phase Inst O/C 1 Block --- --- --- F87 0 = Disabled
2085 Reserved
↓↓ ↓ ↓↓↓ ↓
208F Reserved
WINDING 3
PHASE INST
O/C 1
2090 Winding 3 Phase Inst O/C 1 Function --- --- --- F30 1 = Enabled
2091 Winding 3 Phase Inst O/C 1 Target --- --- --- F46 1 = Latched
2092 Winding 3 Phase Inst O/C 1 Pickup 0.05 to 20.00 0.01 x CT F3
1000=10.00 x CT
2093 Winding 3 Phase Inst O/C 1 Delay 0 to 60000 1 ms F1 0 ms
2094 Winding 3 Phase Inst O/C 1 Block --- --- --- F87 0 = Disabled
2095 Reserved
↓↓ ↓ ↓↓↓ ↓
209F Reserved
WINDING 1
PHASE INST
O/C 2
20A0 Winding 1 Phase Inst O/C 2 Function --- --- --- F30 1 = Enabled
20A1 Winding 1 Phase Inst O/C 2 Target --- --- --- F46 1 = Latched
20A2 Winding 1 Phase Inst O/C 2 Pickup 0.05 to 20.00 0.01 x CT F3
1000=10.00 x CT
20A3 Winding 1 Phase Inst O/C 2 Delay 0 to 60000 1 ms F1 0 ms
20A4 Winding 1 Phase Inst O/C 2 Block --- --- --- F87 0 = Disabled
20A5 Reserved
↓↓ ↓ ↓↓↓ ↓
20AF Reserved
WINDING 2
PHASE INST
O/C 2
20B0 Winding 2 Phase Inst O/C 2 Function --- --- --- F30 1 = Enabled
20B1 Winding 2 Phase Inst O/C 2 Target --- --- --- F46 1 = Latched
20B2 Winding 2 Phase Inst O/C 2 Pickup 0.05 to 20.00 0.01 x CT F3
1000=10.00 x CT
Table 8–6: 745 MEMORY MAP (Sheet 36 of 57)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
