8-54 745 Transformer Management Relay GE Power Management
8.3 MODBUS MEMORY MAP 8 COMMUNICATIONS
8
WINDING 3
NEUTRAL
TIME O/C
continued
20F5 Winding 3 Neutral Time O/C Reset --- --- --- F68 1 = Linear
20F6 Winding 3 Neutral Time O/C Block --- --- --- F87 0 = Disabled
20F7 Reserved
↓↓ ↓
↓↓↓ ↓
20FF Reserved
WINDING 1
NEUTRAL
INST O/C 1
2100 Winding 1 Neutral Inst O/C 1 Function --- --- --- F30 1 = Enabled
2101 Winding 1 Neutral Inst O/C 1 Target --- --- --- F46 1 = Latched
2102 Winding 1 Neutral Inst O/C 1 Pickup 0.05 to 20.00 0.01
×
CT F3
1000=10.00
×
CT
2103 Winding 1 Neutral Inst O/C 1 Delay 0 to 60000 1 ms F1 0 ms
2104 Winding 1 Neutral Inst O/C 1 Block --- --- --- F87 0 = Disabled
2105 Reserved
↓↓ ↓
↓↓↓ ↓
210F Reserved
WINDING 2
NEUTRAL
INST O/C 1
2110 Winding 2 Neutral Inst O/C 1 Function --- --- --- F30 0 = Disabled
2111 Winding 2 Neutral Inst O/C 1 Target --- --- --- F46 1 = Latched
2112 Winding 2 Neutral Inst O/C 1 Pickup 0.05 to 20.00 0.01
×
CT F3
1000=10.00
×
CT
2113 Winding 2 Neutral Inst O/C 1 Delay 0 to 60000 1 ms F1 0 ms
2114 Winding 2 Neutral Inst O/C 1 Block --- --- --- F87 0 = Disabled
2115 Reserved
↓↓ ↓
↓↓↓ ↓
211F Reserved
WINDING 3
NEUTRAL
INST O/C 1
2120 Winding 3 Neutral Inst O/C 1 Function --- --- --- F30 0 = Disabled
2121 Winding 3 Neutral Inst O/C 1 Target --- --- --- F46 1 = Latched
2122 Winding 3 Neutral Inst O/C 1 Pickup 0.05 to 20.00 0.01
×
CT F3
1000=10.00
×
CT
2123 Winding 3 Neutral Inst O/C 1 Delay 0 to 60000 1 ms F1 0 ms
2124 Winding 3 Neutral Inst O/C 1 Block --- --- --- F87 0 = Disabled
2125 Reserved
↓↓ ↓
↓↓↓ ↓
212F Reserved
WINDING 1
NEUTRAL
INST O/C 2
2130 Winding 1 Neutral Inst O/C 2 Function --- --- --- F30 0 = Disabled
2131 Winding 1 Neutral Inst O/C 2 Target --- --- --- F46 1 = Latched
2132 Winding 1 Neutral Inst O/C 2 Pickup 0.05 to 20.00 0.01
×
CT F3
1000=10.00
×
CT
2133 Winding 1 Neutral Inst O/C 2 Delay 0 to 60000 1 ms F1 0 ms
2134 Winding 1 Neutral Inst O/C 2 Block --- --- --- F87 0 = Disabled
2135 Reserved
↓↓ ↓
↓↓↓ ↓
213F Reserved
Table 8–6: 745 MEMORY MAP (Sheet 38 of 57)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
