8-56 745 Transformer Management Relay GE Power Management
8.3 MODBUS MEMORY MAP 8 COMMUNICATIONS
8
WINDING 3
GROUND TIME
O/C
2180 Winding 3 Ground Time O/C Function --- --- --- F30 0 = Disabled
2181 Winding 3 Ground Time O/C Target --- --- --- F46 1 = Latched
2182 Winding 3 Ground Time O/C Pickup 0.05 to 20.00 0.01 x CT F3 85 = 0.85 x CT
2183 Winding 3 Ground Time O/C Shape --- --- --- F36 0 = Ext Inverse
2184 Winding 3 Ground Time O/C Multiplier 0.00 to 100.00 0.01 --- F3 100 = 1.00
2185 Winding 3 Ground Time O/C Reset --- --- --- F68 1 = Linear
2186 Winding 3 Ground Time O/C Block --- --- --- F87 0 = Disabled
2187 Reserved
↓↓ ↓ ↓↓↓ ↓
218F Reserved
WINDING 1
GROUND INST
O/C 1
2190 Winding 1 Ground Inst O/C 1 Function --- --- --- F30 0 = Disabled
2191 Winding 1 Ground Inst O/C 1 Target --- --- --- F46 1 = Latched
2192 Winding 1 Ground Inst O/C 1 Pickup 0.05 to 20.00 0.01 x CT F3
1000=10.00 x CT
2193 Winding 1 Ground Inst O/C 1 Delay 0 to 60000 1 ms F1 0 ms
2194 Winding 1 Ground Inst O/C 1 Block --- --- --- F87 0 = Disabled
2195 Reserved
↓↓ ↓ ↓↓↓ ↓
219F Reserved
WINDING 2
GROUND INST
O/C 1
21A0 Winding 2 Ground Inst O/C 1 Function --- --- --- F30 0 = Disabled
21A1 Winding 2 Ground Inst O/C 1 Target --- --- --- F46 1 = Latched
21A2 Winding 2 Ground Inst O/C 1 Pickup 0.05 to 20.00 0.01 x CT F3
1000=10.00 x CT
21A3 Winding 2 Ground Inst O/C 1 Delay 0 to 60000 1 ms F1 0 ms
21A4 Winding 2 Ground Inst O/C 1 Block --- --- --- F87 0 = Disabled
21A5 Reserved
↓↓ ↓ ↓↓↓ ↓
21AF Reserved
WINDING 3
GROUND INST
O/C 1
21B0 Winding 3 Ground Inst O/C 1 Function --- --- --- F30 0 = Disabled
21B1 Winding 3 Ground Inst O/C 1 Target --- --- --- F46 1 = Latched
21B2 Winding 3 Ground Inst O/C 1 Pickup 0.05 to 20.00 0.01 x CT F3
1000=10.00 x CT
21B3 Winding 3 Ground Inst O/C 1 Delay 0 to 60000 1 ms F1 0 ms
21B4 Winding 3 Ground Inst O/C 1 Block --- --- --- F87 0 = Disabled
21B5 Reserved
↓↓ ↓ ↓↓↓ ↓
21BF Reserved
WINDING 1
GROUND INST
O/C 2
21C0 Winding 1 Ground Inst O/C 2 Function --- --- --- F30 0 = Disabled
21C1 Winding 1 Ground Inst O/C 2 Target --- --- --- F46 1 = Latched
21C2 Winding 1 Ground Inst O/C 2 Pickup 0.05 to 20.00 0.01 x CT F3
1000=10.00 x CT
21C3 Winding 1 Ground Inst O/C 2 Delay 0 to 60000 1 ms F1 0 ms
Table 8–6: 745 MEMORY MAP (Sheet 40 of 57)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
