GE 745 TRANSFORMER MANAGEMENT RELAY User Manual

8-70 745 Transformer Management Relay GE Power Management
8.3 MODBUS MEMORY MAP 8 COMMUNICATIONS
8
CALIBRATION
DATA
continued
5139 Ambient Temperature RTD Input Low Offset –600 to +600 1 --- F4 0
513A Ambient Temperature RTD Input Low Gain 0 to 20000 1 --- F1 8192
513B Ambient Temperature RTD Input High Offset –600 to +600 1 --- F4 0
513C Ambient Temperature RTD Input High Gain 0 to 20000 1 --- F1 8192
513D Analog Input 1 mA Offset –600 to +600 1 --- F4 0
513E Analog Input 1 mA Gain 0 to 2000 1 --- F1 1112
513F Analog Input 20 mA Offset –600 to +600 1 --- F4 0
5140 Analog Input 20 mA Gain 0 to 30000 1 --- F1 22244
5141 Analog Output #1 Min Scale 0 to 4095 1 --- F1 0
5142 Analog Output #1 Max Scale 0 to 4095 1 --- F1 4095
5143 Analog Output #2 Min Scale 0 to 4095 1 --- F1 0
5144 Analog Output #2 Max Scale 0 to 4095 1 --- F1 4095
5145 Analog Output #3 Min Scale 0 to 4095 1 --- F1 0
5146 Analog Output #3 Max Scale 0 to 4095 1 --- F1 4095
5147 Analog Output #4 Min Scale 0 to 4095 1 --- F1 0
5148 Analog Output #4 Max Scale 0 to 4095 1 --- F1 4095
5149 Analog Output #5 Min Scale 0 to 4095 1 --- F1 0
514A Analog Output #5 Max Scale 0 to 4095 1 --- F1 4095
514B Analog Output #6 Min Scale 0 to 4095 1 --- F1 0
514C Analog Output #6 Max Scale 0 to 4095 1 --- F1 4095
514D Analog Output #7 Min Scale 0 to 4095 1 --- F1 0
514E Analog Output #7 Max Scale 0 to 4095 1 --- F1 4095
514F Analog Output #8 Reference 0 to 4095 1 --- F1 4095
5150 Reserved
↓↓ ↓ ↓↓↓ ↓
515F Reserved
ANALOG
OUTPUT
D/A
COUNTS
5160 Force Analog Output 1 D/A Count 0 to 4095 1 --- F1 0
5161 Force Analog Output 2 D/A Count 0 to 4095 1 --- F1 0
5162 Force Analog Output 3 D/A Count 0 to 4095 1 --- F1 0
5163 Force Analog Output 4 D/A Count 0 to 4095 1 --- F1 0
5164 Force Analog Output 5 D/A Count 0 to 4095 1 --- F1 0
5165 Force Analog Output 6 D/A Count 0 to 4095 1 --- F1 0
5166 Force Analog Output 7 D/A Count 0 to 4095 1 --- F1 0
5167 Reserved
↓↓ ↓ ↓↓↓ ↓
516F Reserved
Table 8–6: 745 MEMORY MAP (Sheet 54 of 57)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
