GE 745 TRANSFORMER MANAGEMENT RELAY User Manual

GE Power Management 745 Transformer Management Relay 5-15
5 SETPOINTS 5.2 AUTO-CONFIGURATION
5
Y/d210°/
d150°
1
WYE
(gnd 1/2)
210°
lag
2
DELTA
210° lag
0°
3
DELTA
150° lag
60° lag
Y/d210°/
d210°
1
WYE
(gnd 1/2)
210°
lag
2
DELTA
210° lag
0°
3
DELTA
210° lag
0°
Y/d210°/
d330°
1
WYE
(gnd 1/2)
210°
lag
2
DELTA
210° lag
0°
3
DELTA
330° lag
240°
lag
Y/d330°/y0°
1
WYE
(gnd 1/2)
330°
lag
2
DELTA
330° lag
0°
3
WYE
(gnd 2/3)
0°
330°
lag
Table 5–1: TRANSFORMER TYPES (Sheet 11 of 26)
TRANSFORMER
TYPE
WDG
#
CONNECTION
VOLTAGE
PHASORS
PHASE
SHIFT
Y/d330°/
y180°
1
WYE
(gnd 1/2)
330°
lag
2
DELTA
330° lag
0°
3
WYE
(gnd 2/3)
180° lag
150°
lag
Y/d330°/d30°
1
WYE
(gnd 1/2)
330°
lag
2
DELTA
330° lag
0°
3
DELTA
30° lag
300°
lag
Y/d330°/
d150°
1
WYE
(gnd 1/2)
330°
lag
2
DELTA
330° lag
0°
3
DELTA
150° lag
180°
lag
Y/d330°/
d210°
1
WYE
(gnd 1/2)
330°
lag
2
DELTA
330° lag
0°
3
DELTA
210° lag
120°
lag
Table 5–1: TRANSFORMER TYPES (Sheet 12 of 26)
TRANSFORMER
TYPE
WDG
#
CONNECTION
VOLTAGE
PHASORS
PHASE
SHIFT
