NetworX Version 3 Installation Manual
208
Message Description
Sending SMS The module is sending a report to the SMS destination.
Using GSM Audio
The module is sending an audio report from the control to the audio
destination.
Using GSM CSD The module is sending data.
GPRS Connected The module is communicating with the GPRS network.
Good RSSI Good level of the received signal.
Power Battery Fault There is a problem with the main battery.
SM PSU Fault
There is a problem with the 3.8 V power supply for the GPRS modem
caused by a problem with the main battery.
Bus Power Fault
There is a problem with the 13.8 V voltage supplied by the bus to the
module.
Troubleshooting
Table 27. Troubleshooting problems and solutions
Problem Caused by Do this
The module is not sending messages.
The antenna is faulty or
missing.
Ensure the antenna is attached. Replace the
old or faulty antenna.
The SIM PIN Accepted message is off. The
module provides GSM modem
information but no GSM operation works.
The SIM card is not inserted or
inserted incorrectly.
Insert the SIM card correctly.
The SIM card is blocked. The SIM PIN
Accepted message is off and the SIM PUK
Required message is displayed.
The SIM PIN code is not
correctly programmed.
Insert the SIM card into a mobile phone and
enter the PUK code.
The Logged into GSM Network message is
off and the Current Operator menu entry
is blank.
The GSM operator ID number
is incorrect.
Enter 00000 to enable automatic operator
selection.
Autotest
You can run a periodic autotest to ensure the system is working correctly. Autotest parameters are
configured on the control panel. You can configure the control panel to run autotests and place
autotest events in the event log without reporting them. You can then configure the GSM/GPRS
module to report the autotest events. You must enable the autotest event in the Control Panel menu,
using Events>Communications>Test Reports options.
