GE NetworX V3 User Manual

NetworX Version 3 Installation Manual
13
NetworX V3 technical specifications
Table 1. Available NetworX V3 panel models
Panel models Onboard zones capacity
NX-5
0
NX-7
6
NX-9, NX-11
8
NX-10
2
Table 2. NetworX V3 technical specifications
Mains power specifications NX-xx(-GSM)-EUR NX-xx(-GSM)-LB-EUR
Mains input voltage
230 VAC +10%, −15%, 50Hz
±10%, 25 VA
230 VAC +10%, −15%, 50Hz ±10%,
40 VA
Current consumption at 230 VAC
120 mA typical, 300mA max. 200 mA typical, 500mA max.
Main board supply voltage (AC: CON8)
16.5 VAC typical
Power supply specifications NX-xx(-GSM)-EUR NX-xx(-GSM)-LB-EUR
Power supply type
Type A, EN 50131-6
Power supply voltage [5]
Min. 9.5 V ± 2%
Typ. 13.8 V ± 2%
Max. 14.4 ± 2%
Power supply current
0.9 A max. at 13.8 V ± 2% 1.8 A max. at 13.8 V ± 2%
Main board consumption:
Non-GSM variant
GSM variant
145 mA ± 10% at 13.8 V ± 2%
180 mA ± 10% at 13.8 V ± 2%
Maximum system current available [1]
Non-GSM variant
GSM variant
740 mA max. at 13.8 V ± 2%
700 mA max. at 13.8 V ± 2%
1640 mA max. at 13.8 V ± 2%
1600 mA max. at 13.8 V ± 2%
Auxiliary power output (AUX PWR+,
POS) [2]
See Table 2 See Table 3
Battery type
Lead acid rechargeable,
7.2 Ah 12 V nom. (BS127N)
Lead acid rechargeable,
7.2 Ah 12 V nom. (BS127N) or 12 Ah
12 V nom. (BS130N)
Maximum voltage at power supply,
auxiliary power output and battery
power output
14.4 V
Battery low condition
11.6 V
Deep discharge protection [7]
9.7 V
Maximum ripple voltage Vpp [3]
300 mV typical, 600 mV max.

GE NetworX V3 Specifications

General

Brand	GE
Model	NetworX V3
Category	Security System
Language	English
