Programming outputs
Figure 16. Outputs menu
The control panel includes up to 2 programmable on-board auxiliary outputs. To program on-board
outputs, select Installer Menu>Control Panel>Outputs.
Configuring an output
You can change the characteristics of each output. You must specify the events and/or partitions that
activate an output and the length of time for which the output is activated. The events are grouped in
the programming tree. A full list of all possible selectable events can be found in the
Table 16,
Control panel output events. The following example configures output 1 to activate for 15 minutes
when a burglary alarm occurs.
1. Navigate with the ½¾ keys to Control Panel>Outputs>Prog Outputs>Output 1 and
press OK.
2. Scroll to Event>Alarms>Burglary Alarm and press OK.
3. The keypad beeps once to confirm the change and returns to Alarms.
4. Scroll to Time Unit>Minutes and press OK.
1 (< >)Any Siren
Event
Alarms
Arm/Disarm
Communications
Keypads
Sirens
Tamper/Fa u l t
Tes ts
Miscellaneous
2.2.1.1.1
2.2.1.1.1.1
2.2.1.1.1.8
2.2.1.1.1.7
2.2.1.1.1.6
2.2.1.1.1.5
2.2.1.1.1.4
2.2.1.1.1.3
2.2.1.1.1.2
Prog Outputs 2.2.1 2.2.1.1
Outputs 2 - 4
Same as above
Sounds On
Short Blast On
Output Signal Type
Sound On
Time Unit
Time
Partitions
Attributes
Phone Line Cut
Tam p ers
Expander Trouble
Cross Zone Verification
Arming
Exit Expir
Closing Kissoff
Keys witch Arming
Delay ed
Phone Line Cut
Mains Failure
Low Battery
Tam p ers
Expander
Cross Zone Verification
Tr ouble
Emergency Keys
Latched
Code Stops Timer
Only if Closed
Only if Open
Inverted
External Siren
When Armed
When Disarmed
When Armed
When Disarmed
2.2.1.1.2
2.2.1.1.5
2.2.1.1.4
2.2.1.1.3
2.2.2.1.1
2.2.2.2.1
2.2.2.2.4
2.2.2.2.3
2.2.2.2.2
2.2.3.1.1
2.2.3.1.6
2.2.3.1.5
2.2.3.1.4
2.2.3.1.3
2.2.3.1.2
2.2.3.1.1.1
2.2.1.1.5.1
2.2.1.1.5.5
2.2.1.1.5.4
2.2.1.1.5.3
2.2.1.1.5.2
2.2.2.1.1.1
2.2.2.1.3
2.2.2.1.2
2.2.2.1.1.2
2.2.3.1.1.2
Internal Siren
Keypads
2.2.2
2.2.3
2.2.2.1
2.2.2.2
2.2.2.3
2.2.3.1
2.2.2.1.4
2.2.3.1.7
2.2.1.1.5.6
