NetworX Version 3 Installation Manual

262

NX-1701E door swipe modules

Table 45. NX-1701E module numbers

Learn-in sequence Module number Learn-in sequence Module number

1 113 9 121

2 114 10 122

3 115 11 123

4 116 12 124

5 117 13 125

6 118 14 126

7 119 15 127

8 120

Keypads

Table 46. Keypad module numbers

Keypad Partition 1 Partition 2 Partition 3 Partition 4

1 192 193 194 195

2 200 201 202 203

3 208 209 210 211

4 216 217 218 219

5 224 225 226 227

6 232 233 234 235

7 240 241 242 243

8 248 249 250 251
