GE NetworX V3

NetworX Version 3 Installation Manual
36
Figure 13. Wireless outdoor siren
1
Siren PCB
8
Tamper
2
Speaker
9
Tamper
3
Beacon
A
Open collector output 2 (+) for beacon
4
3X lithium battery pack
B
Open collector output 2 (-) for beacon
5
IO module power cable (black)
C
Open collector output 1 (+) for speaker
6
IO module power cable (blue)
D
Open collector output 1 (-) for speaker
