GE Vivid E9

GE H EALTHCARE
D IRECTION GA091568, R EVISION 5 VIVID E9 S ERVICE M ANUAL
Chapter 8 - Replacement procedures 8 - 271
8-11-4-8-3 Cables for the Nvidia Quadro FX1800 / Nvidia Quadro 2000D - BEP5
Figure 8-239 Cables on the Nvidia Quadro FX1800 / Nvidia Quadro 2000D card - BEP5
1. I/O Unit
2. Graphics Adapter (Nvidia Quadro FX1800 / Nvidia Quadro 2000D)
3. DVR Board (stipulated position to the left, installed to the right)
4. DVI Out cable
5. DVI Flex Main cable
6. SATA cable (Don’t disconnect in this procedure)
