GE DRAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

Chapter 3 - Setup Instructions 3-67

Section 3-9

Available Probes

See Chapter 9 - Probes, on page 9-20, for part numbers to be used when ordering new or replacement

service probes.

Section 3-10

Software/Option Configuration

For description refer to:

• Section 3-8-1 "System Setup" on page 3-55

NOTICE

!! NOTICE:

More detailed information pertaining System Setup and Measure Setup adjustments is found in the

Voluson™ P8/Voluson™P6 Basic User Manual, which is available in different languages.
