GE Voluson P6 - Section 8-14 Replacement of REAR CABINET BEZEL ASSY BT16; 8-14-1 Manpower; 8-14-2 Tools; 8-14-3 Disassembly Procedure

To Next Page

To Previous Page

GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

8-34 Section 8-14 - Replacement of REAR CABINET BEZEL ASSY BT16

Section 8-14

Replacement of REAR CABINET BEZEL ASSY BT16

8-14-1 Manpower

1 person, 1 minute

8-14-2 Tools

Not required

8-14-3 Disassembly Procedure

1.) Remove the Rear Cabinet BEZEL ASSY BT16. Refer to the figure below.

8-14-4 Installation Procedure

Install the new parts in the reverse order of removal procedure.

Figure 8-36 Removing the REAR CABINET BEZEL ASSY BT16

REAR CABINET BEZEL ASSY

BT16
