GE DRAFT VOLUSON™ P8/VOLUSON™P6
DIRECTION 5775469, R
EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-33
3.) Install the Self-Adhesive Hook and Loop set on the TRAY PEDESTAL CABINET PLASTIC BT16.
Refer to the figure below.
4.) Remove the Paper and place the TRAY PEDESTAL CABINET PLASTIC on the System Pedestal.
Refer to the figure below.
Figure 8-34 Installing the Self-Adhesive Hook and Loop set
Figure 8-35 Removing the Paper and placing the TRAY PEDESTAL CABINET PLASTIC BT16
Stick the self-adhesive hook and loop set on the TRAY
PEDESTAL CABINET PLASTIC BT16. Align it with the locator
pillars and stick at center.
Place the TRAY PEDESTAL CABINET PLASTIC BT16
on the system pedestal.
To Next Page
