GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

8-130 Section 8-42 - Replacement of the DRFG

8-42-4 Removal Procedure

1.) Draw the DRFG out of the Nest Frame.

Figure 8-188 DRFG

Figure 8-189 Drawing the DRFG

DRFG
