GE Voluson P6 - Section 8-36 Replacement of the Caster Cap BT16; 8-36-1 Manpower; 8-36-2 Tools; 8-36-3 Preparations

To Next Page

To Previous Page

GE DRAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-115

Section 8-36

Replacement of the Caster Cap BT16

8-36-1 Manpower

One person, 2 minutes

8-36-2 Tools

None

8-36-3 Preparations

1.) Power Off/Shutdown the system as described in 4-3-2 on page 4-4.

NOTE: Lock Caster before removing it.

8-36-4 Removal Procedure

1.) Remove the FRONT CABINET BEZEL ASSY BT16. Refer to the figure below.

Figure 8-168 Removing the FRONT CABINET BEZEL ASSY BT16

FRONT CABINET BEZEL

ASSY BT16
