8-116 Section 8-36 - Replacement of the Caster Cap BT16

2.) Remove the FRONT PRINTER BEZEL ASSY BT16. Refer to the figure below.

3.) Remove the Top Cabinet Cover BT16. Refer to the figure below.

Figure 8-169 Removing the FRONT PRINTER BEZEL ASSY BT16

Figure 8-170 Removing the Top Cabinet Cover BT16

FRONT PRINTER BEZEL

ASSY BT16

TOP CABINET COVER

BT16
