8-92 Section 8-27 - Remove the PEDESTAL BOTTOM COVER BT16

Section 8-27

Remove the PEDESTAL BOTTOM COVER BT16

8-27-1 Manpower

One person, 2 minutes

8-27-2 Tools

N/A

8-27-3 Preparations

N/A

8-27-4 Removal Procedure

1.) Remove PEDESTAL BOTTOM COVER BT16. Refer to the figure below.

8-27-5 Installation Procedure

1.) Install the new parts in the reverse order of removal.

Figure 8-138 Removing the PEDESTAL BOTTOM COVER BT16

PEDESTAL BOTTOM COVER BT16
