GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

8-40 Section 8-16 - Replacement of Power ON/OFF key PCB Assembly

Section 8-16

Replacement of Power ON/OFF key PCB Assembly

8-16-1 Manpower

One person, 30 minutes

8-16-2 Tools

Philips screw driver

8-16-3 Disassembly procedure

1.) Unscrew 9 screws at the bottom of the keyboard body. Refer to the figures below.

Figure 8-46 Unscrewing 9 screws
