GE RAFT VOLUSON™ P8/VOLUSON™P6
DIRECTION 5775469, R
EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL
7-30 Section 7-6 - Common Service Desktop (CSD)
Contents in this section : For Automatic diagnostic Test, Please refer to below table
7-6-2-3-1 Probe Assessment Tool (ePAT)
This test checks the functionality and sensitivity of probe elements.
NOTE: Matrix array probes (1.25 and 1.5 arrays) cannot be tested with ePAT.
Pre-work
Detach all probes and run DBMG tests (CSD - Diagnostics - HW Tests) to make sure that there is no
defective FrontEnd hardware component that interferes the ePAT test.
ePAT Procedure
7-7-3-2
VPD
page 7 - 54
7-7-3-3
DRFG Overall Test
page 7 - 55
7-7-3-6
DPS
page 7 - 57
7-7-3-4
DBM64G
page 7 - 56
7-7-3-5
DPI
page 7 - 57
7-7-3-8
Battery
page 7 - 58
• Clean probes before the test. Any remaining coupling gel will disturb
measurements.
• Do not allow the probe head to hang free. Impact to the probe head could result in
irreparable damage.
• For Volume probes (e.g., RAB, RIC,....), which are filled with oil, it is recommended
to position the head horizontally in such a way that any air bubbles are moved
away from the array. Wait some seconds until air bubbles are surely moved aside.
