8-2 Section 8-1 - Overview
8-14
Replacement of REAR CABINET BEZEL ASSY BT16
8-34
8-15
Replacement of ENCODER set
8-35
8-16
Replacement of Power ON/OFF key PCB Assembly
8-40
8-17
Replacement of Keyboard Assembly-TOP
8-46
8-18
Replacement of OPIO BUTTON SET
8-51
8-19
Replacement of OPIO Plastic lower cover assy
8-56
8-20
Replacement of OPIO Plastic upper cover assy
8-62
8-21
Replacement of Monitor
8-67
8-22
Replacement of the MONITOR ARM
8-69
8-23
Replacement of LCD Cable
8-72
8-24
Replacement of ASSY Bumper Base Rubber
8-81
8-25
Replacement of OPIO
8-87
8-26
Replacement of the SPEAKER
8-91
8-27
Remove the PEDESTAL BOTTOM COVER BT16
8-92
8-28
Replacement of the NEST
8-93
8-29
Replacement of the AIR FILTER
8-98
8-30
Replacement of the Probe Holder(KIT)
8-100
8-31
Replacement of SIDE COVER L ASSY BT16
8-101
8-32
Replacement of SIDE COVER R ASSY
8-103
8-33
Replacement of the Trackball
8-106
8-34
Replacement of the TGC BOARD
8-111
8-35
Replacement of AN KEYBOARD ASSY
8-113
8-36
Replacement of the Caster Cap BT16
8-115
8-37
Replacement of the CASTER
8-121
8-38
Replacement of the SIDE CABINET TRAY BT16
8-123
8-39
Replacement of the REAR HANDLE
8-124
8-40
Replacement of the SPEAKER COVER LEFT/RIGHT
8-127
8-41
Replacement of the DPS/DPS with Battery
8-128
8-42
Replacement of the DRFG
8-130
8-43
Replacement of the SOM in DRFG
8-136
8-44
Replacement of the HDD in DRFG
8-137
8-45
Replacement of the DBM64G
8-138
8-46
Replacement of the T-DPI
8-140
8-47
Replacement of the CSI
8-143
8-48
Replacement of the DBP
8-145
Table 8-1 Chapter 8 Contents
Section Description Page Number
