GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

8-38 Section 8-15 - Replacement of ENCODER set

7.) After removing trackball, unscrew 21 screws and disconnect TGC cable. And lift up the main

keyboard circuit board. Refer to the figure below.

Figure 8-43 Lifting up the main keyboard circuit board after unscrew 21 screws and disconnecting TGC cable

TCG cable
