GE DRAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-63

2.) Remove 5 probe holders. Refer to the figure below.

3.) Lift up main keyboard assy. Refer to the figure below.

Figure 8-83 Removing 5 probe holders

Figure 8-84 Lifting up main keyboard assy
