GE RAFT VOLUSON™ P8/VOLUSON™P6
DIRECTION 5775469, R
EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL
8-88 Section 8-25 - Replacement of OPIO
3.) Remove the 5 probe holders. Refer to the figure below.
4.) Unscrew 9 screws located in the bottom of the OPIO. Refer to the figure below.
Figure 8-131 Removing the 5 probe holders
Figure 8-132 Unscrewing 9 screws located on the bottom of the OPIO
