GE RAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

8-94 Section 8-28 - Replacement of the NEST

2.) Remove the REAR CABINET BEZEL ASSY BT16. Refer to the figure below.

3.) Unscrew 7 screws and remove the REAR EMI COVER BRKT. Refer to the figure below.

Figure 8-140 Removing the Rear Cabinet Bezel Assy BT16

Figure 8-141 Removing the REAR EMI COVER BRKT

REAR CABINET BEZEL ASSY BT16
