Chapter 8 - Replacement Procedures 8-157

21.)Screw the 7 screws and fix the REAR EMI COVER.

22.)Assemble the REAR CABINET BEZEL ASSY BT16, power cord and POWER CORD FIX

BRACKET.

23.)Assemble the FRONT PRINTER BEZEL ASSY BT16.

Figure 8-223 Assembling rear side parts

Screw the 7 screws

Assemble power cord and

FRONT PRINTER BEZEL

FRONT PRINTER BEZEL ASSY BT16

ASSY BT16
