GE DRAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

Chapter 3 - Setup Instructions 3-7

Remove the top cover and top plate.

Remove the three Plastic Joints from the outer sleeve..

Remove the outer sleeve and the monitor pad.

Table 3-5 Unpacking Procedure

Step Task
