4. Perform the EDV measurement using the trackball and press the right/left trackball key
[Set] again.
Note
The measurement results of PSV, EDV, RI and S/D are displayed and stored in the report.
11.2.2.17 Time
To measure the Time in Spectral Doppler Mode:
1. Press the [Calc] key on the control panel.
2. Select the desired item. For example: select [Left Renal Artery].
3. To measure a horizontal time interval, select the [Time] key. A line appears in the
screen.
4. Move the line to the start point of the measurement and press the right or left trackball
key [Set].
Note
To re-adjust the start point, press the upper trackball key. A second line (parallel to the first
one) appears.
5. Move this line using the trackball to the end point of the measurement and then press
[Set].
11.2.2.18 HR (Heart Rate)
To measure the Heart Rate (HR) in Spectral Doppler Mode:
1. Press the [Calc] key on the control panel.
2. Select the desired item. For example: select [Left Renal Artery].
3. Select the [HR] item on the menu area. A line appears on the screen.
4. Move the line to the start point of the period and press the right or left trackball key [Set].
The second line appears.
5. Select the number of heart rate cycles for the measurement with the rotary control.
6. Move the second line to the end point of the period (according to the selected number of
heart rate cycles to be measured).
7. Press the right or the left trackball [Set] key again. The Heart Rate is displayed.
11.2.2.19 Abdomen Worksheet
Press the [Worksheet] key on the control panel to view the report that contains detailed results
of abdomen calculations
Measurements and Patient Worksheets (Reports)
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4 11-33
