12.3.5.4 Data Transfer Menu
The options in the data transfer menu depend on what is selected on screen. The options
available, when the exam table is active, are listed below and described in
'Data Transfer
Menu'
on page 12-25
•
DICOM Send
•
Print
•
Export
•
Import
•
Return
12.3.6 Image Area
When an image from the image area is selected, the left margin of the screen and the menu
area show the image menu.
Picture Key Action
Current Patient Opens "Current Patient” Screen,
see'Current Patient Dialog'
on page 12-3
Image History Opens the "Image History" Screen, see
'Image History'
on page 12-30
Exam Review Opens the "Exam Review" Screen, see
'Exam Review'
on page 12-31
Image Properties Allows you to view the Image Properties,
see 'Image Properties'
on page 12-24
.
This button is only available if exactly one
image is selected.
Delete Deletes the currently selected Image, see
'Data Transfer Menu'
on page 12-25
.
Data Transfer Switches to Data Transfer Menu, see 'Data
Transfer Menu'
on page 12-25
Exit Close the "Exam Review" dialog and return
to the running exam.
Search To conduct a search enter the required
criteria and press the [Search] button, see
'Searching for a Particular Exam'
on page
12-13
Show All Shows all Patients, see 'Searching for a
Particular Exam'
on page 12-13
12.3.6.1 Image Properties
Image Properties are similar to Exam Details.
Image Properties: Allows you to view the Image Properties. Click the buttons of the upcoming
window to view image details, study details, series details, equipment details, regional
calculation details, patient details and as seen below file details.
Archive
12-24
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4
