• IEC*61000-4-4: 2kV burst on power lines
• IEC*61000-4-4: 1kV burst on data lines, length above 3m
• IEC*61000-4-5: 1kV differential mode 2kV common mode
• IEC*61000-4-6: 150 kHz-80 MHz, 0.1V (80% AM, 1kHz)
• IEC*61000-4-8: Power frequency magnetic field
• IEC*61000-4-11: voltage dips
Maximum operating
altitude:
3000m; depending on the properties of the connected electronic devices the
maximum operating altitude is limited to the altitude stated in the
corresponding user manual of the connected electronic device
Pollution degree: 2
Overvoltage category: II
Material group: IIIb
Electrical safety: IEC*60601-1(IEC60601-1), UL60601-1
Mechanical safety: IEC*60601-1(IEC60601-1), UL60601-1
Thermal safety: IEC*60601-1(IEC60601-1), UL60601-1
Electro-magnetic influence: In the working frequency range of the ultrasound system from 1 to 16 MHz an
influence on the ultrasound image can be visible in the range from
200..500mV/m depending on the probe connected.
Duty cycle: 100% on
Safety classification: Class I applied parts type BF or type CF acc. to IEC60601
IPX0 : No protection against ingress of water(system)
IPX7 : Probe
IPX8 : footswitch
Ambient temperature: 18ºC to 30ºC resp. +64ºF to +86ºF (operation temp. of instrument)
-10ºC to 50ºC resp. +14ºF to +122ºF (stock temp.)
-10ºC to 50ºC resp. +14ºF to +122ºF (transport temp.)
Barometric pressure: 700 to 1060 hPa (operation condition)
700 to 1060 hPa (stock and transport condition)
Humidity: 30 to 80% RH no condensation (operation condition)
10 to 90% RH no condensation (stock and transport condition)
Humidity protection: covered, no humidity protection
16.2 Physical Attributes
16.2.1 Dimensions / Weight
Width: 620 mm (24.4 in)
Depth: 850 mm (33.4 in)
Technical Data / Information
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4 16-3
